キッチン中国のサプライヤーのための非導電性接着剤付き銅箔テープ

原産地:中国
ブランド名:Xinst
型番:0701/0702/0703
材質:銅箔
特徴:防水
用途:マスキング
接着剤:アクリル
接着剤面:片面
接着剤タイプ:感圧
デザイン印刷:印刷なし
厚さ:0.05 / 0.06 /0.08/0.1/0.15mm
色:銅
使用法:EMI
用途:シールド信号ケーブルまたはFFC
:銅箔
Name:Acrylic Non-Conductive Adhesive Copper Foil Tap

Professional Produce Acrylic Non-Conductive Adhesive Copper Foil Tape Descriptions:

Acrylic Non-Conductive Adhesive Copper Foil Tape is as a smooth copper (purity is 99.95%) foil backing with a acrylic pressure-sensitive adhesive and liner.  It is have conductive or not conductive adhesive. The unplated copper with conductive adhesive is a common EMI shielding tape for non-corrosive conditions.

Acrylic Non-Conductive Adhesive Copper Foil Tape Features:

• Dead soft copper foil backing for good shielding effectiveness, soldering and converting (slitting and die cutting).
• Acrylic pressure-sensitive adhesive has good resistance to heat, oxidation, solvents and oils.
• Removable liner on adhesive side makes it easy to handle. protect the adhesive prior to application and die cut complex shapes.



ロールサイズ: 3" plastic core, Single Copper Foil Tape width: 2mm -600mm; standard width: 600mm, standard length: 50M Special length, thickness or combinations can be supplied per customer's request. Products can be supplied in roll, tape or shapes per customer's request..

寿命: To obtain best performance.  Use this product within 12 months from date of delivery. And store under normal conditions of 60 ºC to 80ºF (16 ºC to 27ºC) and 40 to 60% R.H. in the original carton.



If the pet insulation transformer mylar tape caters to your requirement,  please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We’re equipped with a productive factory at your service.

Acrylic Non-Conductive Adhesive Copper Foil Tape Applications:
• Commonly used for RFI/EMI (radio-frequency interference or electromagnetic interference) shielding and ESD (electrostatic discharge) grounding for components, integrated circuits, connectors, cables, motors, equipment enclosures/cabinets and shielded rooms.
• Conductive circuit or bus bar for low voltage applications
• Used in jobs requiring high conductivity or shielding effectiveness for a given thickness.
• Best used in non-corrosive environments.

• Electrical connection between surfaces (sheets / foils)

• Mounting transparent foils, windows for EMI/RFI shielding

• Shielding in housings and Faraday cages

• Cable shielding (Wrap around the cable)

• Temporary shielding during emission and immunity tests

• Snail Barrier

Acrylic Non-Conductive Adhesive Copper Foil Tape Specifications:

製品コード Xinst0701/0702/0703
名前  Copper foil tape
Thickness(mm) 0.05/0.06/0.08/0.1/0.15
接着剤 Acrylic/Conductive adhesive
バッキング Copper foil/Cu/Cu+PET
Copper
ライナー Paper
Short-term temperature 180
Long-term temperature 120
