3M Polyester film electrical insulating tape 5#

Model Number:3M 5#
Adhesive:Acrylic
Adhesive Side:Single Sided
Adhesive Type:Pressure Sensitive
Design Printing:No printing
Material:Polyester film
Feature:Heat-Resistant
Use:MASKING
SIZE:Customized
Thickness:0.063mm

3M Polyester film electrical insulating tape 5#

3M Polyester film electrical insulating tape, which meets the flame retardance requirements of UL510. It is composed of U-approved insulation materials and has a temperature rating of UL130 degrees Celsius. It has excellent anti-relaxation and solvent resistance properties. Suitable for automation equipment.

Polyester film electrical insulating tape Features

● Polyester film electrical insulating tape, which meets the flame retardance requirements of UL510. It is composed of UL-approved insulation materials and has a UL130 ° C temperature rating.

 ● Acrylic and rubber pressure-sensitive adhesives
 ● Can be printed on the surface
 ● Excellent anti-relaxation and anti-solvent performance
 ● Good moist and smooth, suitable for automated equipment

Our Factory Competitive Advantages:

Well Competitive Prices and High Quality Control

Prompt Delivery

Earth-friendly Products

In a Variety of Design

Small Order Acceptable

OEM Accepted

Roll Size: 3″ paper or plastic core;tape width: 2mm -1200mm; standard width: 1200mm,standard length:50M

OEM Size:Special length, thickness or combinations can be supplied per customer’s request.Products can be supplied in roll,
tape,sheets or shapes per customer’s request.Only you provide the CAD drawing,we can die cut any size for you.

Shelf Life: To obtain best performance, use this product within 12 months from date of delivery and store under normal conditions of 60 ºC to 80ºF (16 ºC to 27ºC) and 40 to 60% R.H. in the original carton



If the 3M Polyester film electrical insulating tape 5# to your requirement, please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We’re equipped with a productive factory at your service.

Applications:

● Coil
● capacitor
● Flat enameled wire
● Transformer
● Sub-horsepower motor
Product Name
3M 5# special type Polyester film electrical insulating tape
Adhesive Type
Acrylic
Filler Type
Ceramic
Dielectric Strength (kV/mm)
26  (688)
Adhesion Strength
35 oz/in (3.8N/10mm)
Temperature Range
-40ºC to 150ºC
Features
 ● 3M 5# special type Polyester film electrical insulating tape, which meets the flame retardance requirements of UL510. It is composed of UL-approved insulation materials and has a UL130 ° C temperature rating.

 ● Acrylic and rubber pressure-sensitive adhesives
 ● Can be printed on the surface
 ● Excellent anti-relaxation and anti-solvent performance
 ● Good moist and smooth, suitable for automated equipment
Thickness
0.063mm
