Replace 3M 9713 YXZ Electrically Conductive Double Side Tape

FOB Price: $1.8-$1.93 Square Meter
Min Order Quantity: 1000 Square Meters
Supply Ability: 15000 Square Meters
Port: Shenzhen, China
Payment Terms: T/T, L/C, Paypal, Western Union
Delivery Time: About 10-15 days

XST-210 Electrically Conductive Double Side Tape provides a better way for applications requiring excellent conductivity.

Besides, XST-210 XYZ Electrically Conductive Double Sided Tape is made of a unique PSA to assure the adhesion to many kinds of substrate such as conductive fabric, aluminum foil, copper foil and so forth.

Electrically Conductive Tape Features:

  • Offer wide range of usage and service temperatures.
  • Excellent electrically conductive performance, XYZ conductivity.
  • Supplied on a removable liner for easy handling and die-cutting.
  • Thinner for avoiding remaining adhesive residual after slitting.

Packaging Details:

Export standard packing for XST-210 Electrically Conductive Double Side Tape. (If customers have special requirements, we also can make accordingly.)

Our Factory Competitive Advantages:

  • Well Competitive Prices and High Quality Control
  • Prompt Delivery
  • Earth-friendly Products
  • In a Variety of Design
  • Small Order Acceptable
  • OEM Accepted

Roll Size: 3″ paper or plastic core;tape width: 2mm -1200mm; standard width: 1200mm,standard length:50M

OEM Size:Special length, thickness or combinations can be supplied per customer’s request.Products can be supplied in roll,
tape,sheets or shapes per customer’s request.Only you provide the CAD drawing,we can die cut any size for you.

Shelf Life: To obtain best performance, use this product within 12 months from date of delivery and store under normal conditions
of 60 ºC to 80ºF (16 ºC to 27ºC) and 40 to 60% R.H. in the original carton



If the Replace 3M 9713 YXZ Electrically Conductive Double Side Tape to your requirement, please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We’re equipped with a productive factory at your service.



  • EMI shielding applications in mobile phone, notebook, PC and other electronic products.
  • EMI shielding applications in connector, FFC and wire stock etc..
  • Die cut pieces and laminate.
Properties No.XST-210
Adhesive Type 400
Carrier Type N.A.
Release Liner Release Liner
Roll Length
Standard
Maximum
20m/50m
50m
Roll Width 1080mm
Adhesive Thickness 0.1mm±10%
Adhesive Color Gray
Slitting Tolerance ±0.4mm
180° Peel Adhesion
(PSTC-101) (N/Inch)
>11.76
Electrical Resistance
(Microhm Meter) (Ohm)
<0.1
Temperature Tolerance
Long Term ℃ (℉)
Short Term ℃ (℉)
120 (248)
180 (356)
Holding Power
(PSTC-7)(Hr)
(1Kg/inch) (25℃)
>18
Initial Tack (PSTC-6 #14)(mm) <200
Temperature Range of Usage -20℃~120℃

Storage and Shelf Life:

Store in original cartons at 23 ±5℃ and 60%±10% relative humidity in order to obtain the best performance, besides using these products within 18 months from the date of manufacture.

Important Notice:

  • This document is the property of XST tape. Please consult with us before using it.
  • This document for any purpose other than that for which it was intended.
  • The data provided herein are measurement only and are not guaranteed. Please make sure the product is capable of the application before actually tempting to put it to use.
  • Users assume all risk and liability associated with such use.
