Die Cut ITW Formex GK-30 black fireproof Insulated PP Paper

Model Number:Formex GK-30
Adhesive:Acrylic
Adhesive Side:Single Sided
Adhesive Type:Pressure Sensitive
Design Printing:No printing
Material:masking Paper
Feature:Heat-Resistant
Use:MASKING
SIZE:Customized
color:black

Die Cut ITW Formex GK-30 Electrical Insulation Material black fireproof Insulated PP Paper

Formex GK-30 is ITW Formex's market-proven flame-retardant polypropylene electrical insulation material formulation that can provide excellent reliability and durability for a variety of industrial and consumer applications.

It provides excellent dielectric strength, high temperature ratings, and excellent moisture and chemical resistance to protect sensitive electronic components from dielectric or environmental damage. It can also be used as a physical barrier to protect ordinary users or service personnel from the danger of contacting live components.

In addition, Formex GK can be easily scored and folded into a 3D shape, making it a highly versatile product, greatly reducing the costs associated with manufacturing, warehousing and transportation.



Applications:
Widely used in household appliances, LED lighting, aerospace, chemical, electronic appliances, machinery, electric vehicles, railways and other industries.

Die cutting designs can includes holes, shapes, oversized lines (for easy removal) and complimentary products can also be incorporated.
Die cutting tapes enable you to save a significant amount of time when applying the adhesive tape and to save money for cuts through slitting.



Our Factory Competitive Advantages:

Well Competitive Prices and High Quality Control
Prompt Delivery
Earth-friendly Products
In a Variety of Design
Small Order Acceptable
OEM Accepted

Roll Size: 3″ paper or plastic core; tape width: 2mm -600mm; standard width: 600mm, standard length: 50M.

OEM Size: Special length, thickness or combinations can be supplied per customer’s request. Products can be supplied in roll, tape, sheets or shapes per customer’s request.Only you provide the CAD drawing, we can die cut any size for you.

Shelf Life: To obtain best performance, use this product within 12 months from date of delivery and store under normal conditions of 60 ºC to 80ºF (16 ºC to 27ºC) and 40 to 60% R.H. in the original carton.



High temperature 3m 471 tape pvc floor marking tape paint masking tape



If the Die Cut ITW Formex GK-30 Electrical Insulation Material black fireproof Insulated PP Paper to your requirement, please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We’re equipped with a productive factory at your service.

Applications:

Widely used in household appliances, LED lighting, aerospace, chemical, electronic appliances, machinery, electric vehicles, railways and other industries.

Die cutting designs can includes holes, shapes, oversized lines (for easy removal) and complimentary products can also be incorporated.
Die cutting tapes enable you to save a significant amount of time when applying the adhesive tape and to save money for cuts through slitting.

Product Name
Die Cut ITW Formex GK-30 Electrical Insulation Material black fireproof Insulated PP Paper
Adhesive Type
acrylic adhesive
Color
Black
Temperature Resistance
-20°C -100°C
Tensile Strength:
1KV
Density:
1.035gm/cc
Features
Flammability rating UL 94 VTM-0.
Water absorption.
Rated temperature 115°C / 239°F.
Dielectric strength 2200V/mil @ 0.005".
UL recognized file E121855.
Thickness
0.76mm
